Amplified by LA2Xi / LA4X / LA8 / LA12X
Low frequency limit (-10 dB) 40 Hz ([SB15_100])
Maximum SPL1 137 dB ([SB15_100]) with LA2Xi (bridge mode) / LA4X / LA8 / LA12X 131 dB ([SB15_100]) with LA2Xi
Nominal directivity (-6 dB)
Standard or cardioid Transducers 1 x 15″ cone driver
Acoustical load Bass-reflex, L-Vents Nominal impedance 8 Ω
1 Peak level at 1 m under half space conditions using pink noise with crest factor 4 (preset specified in brackets).
Physical specs Connectors 2 × 4-point speakON
Rigging and handling 2 x handles 2 x coupling bars and 2 x locking tabs 1 × 35 mm pole socket Cabinet Premium grade Baltic birch plywood Front
Coated steel grill acoustically neutral 3D fabric
Rigging components
High grade steel with anti-corrosion coating
IP45
